Pickleball Court Flooring
High Elasticity Portable 4.5mm Pickleball Court Flooring for All Venues
ltem No.:
BAM-001Material:
PVCSize:
2m*15mThickness:
4.0mm,4.5mm,5.0mm,6.0mm,8.0mmRecommended Thickness:
4.5mmFormat:
RollsProcess:
Compound process sports floorAbrasion Resistance Grade:
T levelBrand:
FARFLY
①PVC Wear Layer
②PVC Decompression Layer
③Fiberglass Mesh Fabric stable Layer
④Closed Foaming Buffer Layer
⑤Dense compressive layer
| Technical Data | ||
| Standard | Test Results | |
| Total Thickness | EN428 | 4.5-12mm(customisable) |
| Thickness of wear layer | EN429 | 1.2mm(customisable) |
| Weight | EN430 | 3.8/4.5/5.4kg/㎡ |
| Roll width | EN426 | 1.8m |
| Roll length | EN426 | 15*20m(customisable) |
| SAFETY CRITERIA | ||
| Vertical deformation | EN14809-2005 | 0.3mm |
| Wear resistance | EN ISO5470-1-1999 | 120mg |
| Indentation resistant | EN 1516-19999 | 0.27mm |
| Impact resistance | EN 1517-19999 | 0.35mm |
| Ball rebound | EN12235 | 95% |
| Frictional | EN13036-4:2011 | 86 |
| Tensile strength | 3.2MPa | |
| Elongation at break | 293% | |
| PRODUCT PERFORMANCE | ||
| Polyethylene monomer | GB 18586-2001 | not detected(<0.5mg/kg) |
| Soluble heavy metals | GB 18586-2001 | not detected(<0.1mg/㎡) |
| Volatile matter | GB 18586-2001 | 24g/㎡ |
| Phthalates | EN 14372-2004 | not detected |
| Fire rating | GB 8624-2012 | B1 |
| Formaldehyde release | EN 147-1:2004 | not detected |
*All of our medical PVC floors have passed major international testing standards.
